| Connection Diameter Machine Side (DCONMS) | 63 mm | Connection Retention Knob Thread Size (CRKS) | M20 |
| Connection Diameter Workpiece Side (DCONWS) | 22 mm | Application | | Face contact interface | |
| Shank Size (SS) | C6 | Tool Type | ISO 26623-1 (CAMFIX, CAPTO) |
| Body Length (LB) | 78 mm | Measurement Type | Metric |
| Body Diameter (BD) | 47 mm | Body Material | Steel |
| Overall Length (OAL) | 100 mm | Unit | M |
Product Features
| Family Description | TungCap shell mill holders (with coolant nozzle) | FamilyName | C-SEM shell mill |
| Remarks | Applicable for 7 MPa coolant. Wrench is not included | BrandName | Tungaloy |
| COO | ISRAEL |
Shipping Info
Weight per item
1.9120
Name
Shell Mill Holders
FamilyName
C-SEM shell mill
BrandName
Tungaloy
