| Cutting Diameter (DC) | 1 mm | Application | | Shoulder Milling | |
| Connection Diameter Machine Side (DCONMS) | 4 mm | Grade | AH725 |
| Depth of Cut Maximum (APMX) | 3 mm | Head Length (LH) | 4.2 mm |
| Overall Length (OAL) | 50 mm | Tool Type | Solid carbide center cutting endmills 90 |
| Cutting Edge Material | Carbide | Maximum Feed per Tooth (fz(max)) | 0.005 mm/tooth |
| Coating | TiAlN | Minimum Feed per Tooth (fz(min)) | 0.003 mm/tooth |
| Flute Count (NOF) | 2 | Body Material | Carbide |
| Shank Type | Round | Measurement Type | Metric |
| End Shape | Square | Unit | M |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium | |
Product Features
| Family Description | 2 flute endmill, 30 deg helix angle | BrandName | Tungaloy |
| COO | ISRAEL | ||
| FamilyName | TEC-A2-C |
Shipping Info
Weight per item
0.0120
Name
Square & Corner Radius End Mills
FamilyName
TEC-A2-C
BrandName
Tungaloy
