‎CNMG 432-27 NS9530

Name: CNMG 432-27 NS9530
Brand: TungTurn
SKU: TUN6998270
Price: 13.35 USD
Availability: InStock

Negative relief ang., M class, 80deg rhombic insert, for finishing to medium cutting

Item # TUN6998270

Brand: Tungaloy

Mfr#: 6998270

Quantity Available

Warning-Proposition 65- For Californian Users only

WARNING: This product contains a chemical known to the State of California to cause cancer or Birth defects. For more information go to www.P65Warnings.ca.gov

Applicable Material

| Steel | Stainless Steel | Cast Iron |

Min D.O.C.

0.0019″

Application

| Inserts |

Depth of Cut Maximum (APMX)

0.0787″

Corner Radius (RE)

0.0314″

Min. Turning Feed (ft(min))

0.0079 ″/rev

Cutting Edge Length (L)

0.508″

Max. Turning Feed (ft(max))

0.0157 ″/rev

Insert Thickness (S)

0.187″

Cutting Direction (HAND)

Neutral

Inscribed Circle Diameter (IC)

1/2″

Chip Breaker Type

Cutting Edge Material

Cermet

Measurement Type

Inch

Coating

Uncoated

Body Material

Carbide

Grade

NS9530

Cutting Edge Effective Length (LE)

0.444″

Fixing Hole Diameter (D1)

0.203″

Unit

Tool Type

Turn Negative Inserts

Product Features

Family Description

Negative relief ang., M class, 80deg rhombic insert, for finishing to medium cutting

BrandName

Tungaloy

COO

JAPAN

Warning-Proposition 65- For Californian Users only

WARNING: This product contains a chemical known to the State of California to cause cancer or Birth defects. For more information go to www.P65Warnings.ca.gov

FamilyName

CNMG-27

Shipping Info

Weight per item

0.1235

Name

Turning Indexable Inserts
